Stainless Steel Twill Weave Mesh

Place of Origin : Hengshui China

Brand Name : XKh

Certification : iso,ce

Model Number : SS wire mesh

MOQ : 1 piece

Packaging Details : Waterproof paper inside ,wooden case

Delivery Time : stock always

Payment Terms : L/C,TT

Price : Price based on quantity

Contact Now

Stainless Steel Twill Weave Mesh

Material:SUS302,304,304L,316,316L stainless steel wire.

Weaving: Twill weave is woven by passing the shute wire over and under two warp wires, creating a sturdier weave. This weave allows for the use of heavier wires, producing a stronger wire mesh.
Stainless Steel Twill Weave Mesh
Characteristics: Flat surface ,no fault .The performances of acid resisting. Alkali-resisting.heat-resisting and wear-resisting

Uses: In mine,oil,chemical industry,food industry,pharmaceutical industry and machine producting

MESH Count	WEAVE	Diameter of Wire		Width of Opening		Open Area	Weight-
MESH Count		Diameter of Wire		Width of Opening		% per	Pounds
per Inch		Inches	mm	Inches	mm	100 Sq. Ft.	per 100Sq.Ft
12 x 12	T	0.032	0.81	0.051	1.3	37.9	78.8
14 x 14	T	0.028	0.71	0.043	1.1	37	70.4
16 x 16	T	0.023	0.58	0.04	1	39.9	54.3
20 x 20	T	0.021	0.53	0.029	0.74	33.6	56.6
30 x 30	T	0.015	0.38	0.018	0.47	30.3	43.3
35 x 35	T	0.014	0.36	0.015	0.37	26	44
40 x 40	T	0.012	0.31	0.013	0.33	27	36.9
50 x 50	T	0.011	0.28	0.009	0.229	20.3	38.8
50 x 50	T	0.0055	0.14	0.015	0.37	52.6	9.7
60 x 60	T	0.011	0.28	0.0057	0.144	11.6	46.6
60 x 60	T	0.0045	0.114	0.012	0.31	53.3	7.8
80 x 80	T	0.007	0.178	0.0055	0.14	19.4	25.1
100 x 100	T	0.005	0.127	0.005	0.127	25	16
120 x 120	T	0.0042	0.107	0.0041	0.105	24.6	13.6
120 x 120	T	0.004	0.102	0.0043	0.11	27	12.3
150 x 150	T	0.003	0.076	0.0037	0.093	30.3	8.7
180 x 180	T	0.0025	0.064	0.0031	0.078	30.3	7.2
200 x 200	T	0.0025	0.064	0.0025	0.064	25	8
200 x 200	T	0.0023	0.058	0.0027	0.069	29.2	6.8
270 x 270	T	0.0016	0.041	0.0021	0.053	32.3	4.4
300 x 300	T	0.0015	0.038	0.0018	0.047	30.3	4.3
325 x 325	T	0.0014	0.036	0.0017	0.043	29.7	4.1
400 x 400	T	0.001	0.025	0.0015	0.038	36	2.6

Stainless Steel Twill Weave Mesh

Stainless Steel Twill Weave Mesh Images
